| Brand Name : | CREE COB ; CREE XPL |
| Model Number : | HEM-FL-10W |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability : | 5000 pieces/month |
| Delivery Time : | 5-8 work days |
Aluminum extruded and die-casting Led flood light MODIS 2(Detachable) Outdoor Lighting
FEATURE:
1.Aluminum extruded and die-casting lamp body, surface outdoor powder electrostatic spraying.
2.Finless housing, compact design, dust-proof.
3.Built-in anti-glare cover, excellent glare control, adjustable projection angle +/-90°
4.Aluminum A7001 forging radiator to ensure sufficient heat dissipation area, excellent thermal management.
5.Simple structure, reliable technology, protection grade IP66.
6.Inductive lightning electrostatic (ESD) protection, in line with LEVEL4 standard.
7.Waterproof light-transmitting valve to prevent condensation of the lamp cavity, balance internal and external pressure.
SPECIFICATIONS
| Items | Modis 2 |
| Model: | HEM-FL-10W(Spike Available) |
| Light distribution: | 1°/3°/5°/15°/30°/60° |
| LED brand: | CREE COB CREE XPL |
| Nominal LED power: | 8-10W |
| Input voltage: | AC220V/DC24V |
| Color temperature: | 2700K- 6500K |
| Control: | ON/OFF |
| Impact protection: | IK08 |
| Ingress protection: | IP66 |
| Driver surge protection: | 10/6 KV |
| Power factor: | > 0.95 |
| Operation temperature: | -40° ~ + 50° |
| Glass/Diffffusor: | Tempered safety glass/Forst Tempered glass/Honey comb |
| Housing: | Corrosion resistant die-cast aluminum housing |
| Lifetime: | L90B50>60, 000; LB8050>60, 000 |
| Finishing: | Silver grey/ Dark grey /Black & optional RAL color |
| Through wiring: | Single cable entry |
Download (2022 OUTDOOR LIGHTING)
https://d1c6gk3tn6ydje.cloudfront.net/1623701818460643328/b210500bcc5e0115d3aae3ca66bb3114.pdf
|
|
